Stone, Marble & Concrete Coatings
Stone & Marble Coatings
More Information & Videos
- Flyer: Stone Coatings (PDF)
- Stone Coatings Comparison (PDF)
- Product Sheet: 620 Stone, Mineral, Concrete Coating + 7620 Penetrating Stain Protector (PDF)
- Product Sheet: 704/705 Multi Stone - Stone, Concrete, Mineral Surfaces Coating (PDF)
- Product Sheet: 7641 Q² Marble PRO Marble Protection System (PDF)
- Product Details: 7641 Hybrid Coating (PDF)
- Product Sheet: 7622 Eco-Stone Topographical Hydrophobic Protection & 8637 High-performance Protection for Monuments (PDF)
- Product Test: Anti-Mold Effect of 7620 Stone Coating (PDF)
- CCM wins the „South West England Prestige Award 2021/22“
Stone Coatings in Comparison
Properties | 7620 Details |
704 / 705 Details |
7641 Details |
7626 Details |
8637 Details |
7622 Details |
7624 Details |
695 Details |
---|---|---|---|---|---|---|---|---|
Application | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller | Brush, roller, convention or airless spray | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller |
Application Temperature | <-10°C - 70°C | <5°C - 40°C | <15°C - 25°C | <-5°C - +60°C | <5°C - 30°C | <5°C - 30°C | 15°C - 25°C | <5°C - 50°C |
m² per liter | 8 - 50 | 20 - 100 | 50 - 80 | 8 - 10 | 10 - 20 | 10 - 20 | 30 - 40 | 5 - 40 |
Durability | 10 - 20 years | 5+ years | Up to 10 years | Up to 20 years | Up to 10 years | Up to three years | 2+ years | Up to 2 years |
Curing Time | 3-6 hours at 20°C | 24 hours | 7 days at room temperature | Touch dry 3-4 hours, full cure 24 hours | 12 hours | 12 hours | 12 hours | 12 hours |
… based | Solvent | Solvent | Solvent | Solvent | Water | Water | Water | Water |
Available as concentrate | No | Dilutable up to 1:1 with Ethanol or 1-Methoxy-2-Propanol | No | No | No | No | No | Yes 1:9-1:14 (art. no. 697) |
Breathable | Yes | No | No | Yes | Yes | Yes | Yes | Yes |
Visible | Might be slightly darker | 704: Glossy 705: Matte |
Yes glossy |
Yes clearly (glossy) |
No on most surfaces |
No on most surfaces |
Matte, transparent | No on most surfaces |
Topographical / penetrative | Penetrative, extreme abrasion-resistant | Topographical | Topographical | Topographical, very strong bonding | Topographical | Topographical | Solidifies the Surface | Topographical |
Oil resistant | Yes | Yes | Yes | Yes | Yes | Yes | No | Yes |
Frost resistant | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
PFOS- / PFOA-free | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
PFAS-free | No | Yes | Yes | Yes | No | No | Yes | Yes |
Available in RAL colors | No | Yes from 1.000 liters |
No | Yes from 100 liters |
No | No | No | No |
Dangerous goods | No | Yes | No | No | No | No | No | No |
Application recommendation | Concrete, tiles (unglazed), roofing tiles, brick/masonry, limestone, sandstone, mineral plaster, natural stone, façade, slate | Concrete, plaster, natural stone (granite, slate, basalt, sandstone, limestone), roof tiles, clinker | Marble | Graffiti Protection for up to 50 times, for commercial locations, for aluminium siding, (fibre) glass, masonry, metal, street signs, stucco, utility boxes, vinyl siding, wood | For monuments, Statues, high value stone art works, paving-stone systems and terrace tiles | Wet room walls, concrete seating in public areas, stone foyer areas | Concrete, plaster, natural stone (granite, slate, basalt, sandstone, |
P-OFF Urine Repellent Coating
Special nano scale coating which is highly suited to protecting stone work from urine. Prevent of urine penetrating and damaging the stone work. Makes cleaning a great deal easier and it also prevents lingering odour created by urine being absorbed into the stone work.
More information on request.
Concrete Coatings
Our concrete additives are extremely well suited as hydrophobic concrete-additive for the manufacturing of paving stones, concrete slabs and prefabricated concrete elements. They improve concretes compaction, regulates the capillary properties of the concrete and reaches a durable reduction of water absorption. The final product is protected against rising moisture. They protect the concrete against limeefflorescences and against the growth of micro-organisms in the product (moss, algae, fungus) The final concrete-product remains vapour-diffusive. They minimises sticking to the stamp and sticking to the concrete-mixer by using a highly-effective non-stick additive.

Product Comparison for Concrete Coatings
Property | 627-10 | 8628 |
---|---|---|
Basis | Siloxan | Silan |
Hydrophobicity effect | Yes | Very strong |
Protection against lime efflorescence | Yes | No |
Prevents concrete-sticking in concrete mixer | Yes | No |
Prevents concrete-sticking of press-plunger | Yes | No |
Capillary regulating characteristic | Yes | Yes |
Vapour diffusive | Yes | Yes |
Plasticising properties (reduces brittleness, less cracking) | Yes | No |
Highly stressable stabilization | Yes | No |
Extremely weather-resistant | Yes | Yes |
Frost and de-icer resistant | Yes | Yes |
Alcali resistant | Yes | Yes |
Oleophobic | Yes | Yes |
Breathable | Yes | Yes |
* 627 is ideal for „flow“ concrete. It offers some degree of hydrophobicity but attain a strongly hydrophobic concrete one should use 8628.
