Textile Coatings: New EU rules – Three technologies from CCM

Since 10 October 2026, new EU restrictions have applied to certain fluorinated chemicals (PFAS). Additional applications will be covered from October 2027. Which products are affected depends on their composition and intended use.

CCM offers technology categories for different requirements and markets:

PFAS-Free and Reduced-PFAS Technologies

7681 and 8685: 100% PFAS-free – without fluorinated active ingredients.
7656 (& concentrate 7658): Fluorinated technology with PFHxA and related substances below the relevant legal limits under EU Regulation 2024/2462.

C4 Technology

789 and 8689 (& concentrate 9685): C4-based fluorinated technology offering high water, oil, grease and stain repellency.

C6 Technology

689 and 7689 (& concentrate 7685): High-performance C6 coatings for applications and markets where their use remains permitted.
687: C6 coating for carpets

Properties

Strong anti-adhesive properties
Excellent easy-to-clean effect with regard to dirt and liquids
Fibres are protected against the ingress of dirt particles
Food-safety
Permanent (UV-stable, very resistant against abrasion)
Temperature-resistant
Easy application
No impairment of the appearance or texture of the substrate (thickness: 100-150 nm)
Free of silicones, FCKW hydrofluorocarbons, teflon, solvents & propellant
Odorless and colorless
Breathable

Ready-to-Use Coatings

Hover um zu scrollen, klicken um aus-/einzublenden

Attribute	789 Product Page	689 Product Page	8689Product Page	7689 Product Page	7681¹ Product Page	7656 Product Page
PFAS free	No - C4	No - C6	No - C4	No - C6	Yes	No²
Application	Spray and let dry	Spray and let dry	Spray and let dry	Spray and let dry	Spray and let dry	Spray and let dry
Application temperature	+5°C to +50°C	+5°C to +50°C	+5°C to +50°C	+5°C to +50°C	+10°C to +25°C	-25°C to +50°C
Durability	Up to 12 months	Up to 12 months	Up to 24 months	Up to 24 months	Up to 24 months	Up to 36 months
Curing time	12 hours at 20°C	12 hours at 20°C	12 hours at 20°C	12 hours at 20°C	24 hours at 20°C	12 hours at 20°C
Perl effect	High	High	High	High	Medium	High
m² per liter	Up to 100m², depends on the density/structure of the substrate	Up to 100m², depends on the density/structure of the substrate	Up to 100m², depends on the density/structure of the substrate	Up to 100m², depends on the density/structure of the substrate	10-30	150
Consistence	Liquid, water-based	Liquid, water-based	Liquid, water-based	Liquid, water-based	Liquid, water-based	Liquid, alcohol-based
UV resistant	Yes	Yes	Yes	Yes	Yes	Yes
Washable	No	No	No	No	No	No
Hydrophobic (water repellent)	Yes	Yes	Yes	Yes	Yes	Yes
Oleophobic (oil repellant)	++	+++	++	+++		+++
Number of components	One	One	One	One	One	One
Concentrate	7685 (1:19)	7685 (1:19)	7685 (1:9)	7685 (1:9)	No	7658
PFOS- / PFOA free	Yes	Yes	Yes	Yes	Yes	Yes

¹ also dilutable 30-50% (weight-%) of 7681, rest filled to 100% (weight-%) with demineralized water. Recommended for synthetic and poly cotton fabrics, not usable on cotton fabrics and absorbent leather. No oleophobicity.
² Complies with the latest European Union Regulation 2024/2462 (<25 ppb for PFHxA and <1000 ppb for total fluorine content).

Concentrates

Attribute	9685Product Page	7685 Product Page	687 Product Page	7658 Product Page	8685 Product Page
PFAS free	No - C4	No - C6	No - C6	No²	Yes
Art. No. ready-to-use	689 (1:19) 7689 (1:9)	689 (1:19) 7689 (1:9)	-	7656	-
Mixing ratio	1:9 – 1:29	1:9 – 1:29	1:25	Kit for 20 liter	1:25 – 1:40
Dilutution with…	demineralized water	demineralized water	demineralized water	- Ethanol (EtOH) 99% or higher (around 16.8 litres) - Hydrochloric acid 37% (HCI), CAS No.: 7647-01-0 (40g)	tap or demineralized water, R2U liquid has a shelf life of 7 days
Number of components	One	One	One	One	Two
Curing time R2U liquid	12 hours at 20°C	12 hours at 20°C	12 hours at 20°C	12 hours at 20°C	12 hours at 20°C
Washable	No	No	No	No	Yes, 10 x maschine waschable
m² per liter ready-to-use	Up to 100m², depends on the density/structure of the substrate	Up to 100m², depends on the density/structure of the substrate	Up to 100m², depends on the density/structure of the substrate	150	10-30
Consistence	Liquid, water-based	Liquid, water-based	Liquid, water-based	Liquid, alcohol-based	Liquid, water-based
UV resistant	Yes	Yes	Yes	Yes	Yes
Hydrophobic (water repellent)	Yes	Yes	Yes	Yes	Yes
Oleophobic (oil repellent)	++	+++	+++	+++
PFOS- / PFOA free	Yes	Yes	Yes	Yes	Yes

HB* SiO2 Coating Technology -
Fluorine Free Liquid Glass Coatings

This stunning technology is completely fluorine free yet provides outstanding hydrophobicity. The range is suitable for use in all areas but specifically, it is designed for use within the DIY/Retail and Commercial sectors where ease of application in a wide range of environments is essential. The coatings perform in a very similar way to our world renowned Liquid Glass coatings in that they create a protective hydrophobic layer which is exceptionally easy to clean.

*HB = hyperbranched silicon dioxide

Flyer: HB SiO2 Coating Technology (Fluorine Free) (pdf)

PFAS-free

Learn more about how we set new industry standards.

Key Attributes

Free from any form of fluorinated agents, essential for use in certain countries
Free from solvents: Alcohol can be added if required for certain applications e.g. leather coating
Ease of application: Easy to apply and very easy to buff when applied to auto surfaces and glass
Excellent easy-to-clean effect: Shower screens, oven fronts and fridge exteriors are cleaned in seconds
Good durability: The coatings will last for approximately one year in areas of low abrasion
Biostatic effect: Reduces proliferation of bacteria
The additives used in order to create HB substrate specific coatings are often commonly used as additives to food or are used in standard domestic cleaning products
