Nano-Scale Liquid Glass Coatings
Stone, Marble & Concrete Coatings
CCM stone and concrete coatings are based on Liquid Glass Technology and provide functional surface protection for mineral substrates. The coatings form a thin, transparent protective layer or penetrate into the pore structure, permanently reducing water absorption, soiling and material-related wear without significantly altering appearance or vapor permeability.
The systems are suitable for concrete, natural and engineered stone, paving, clinker, porcelain stoneware, as well as sensitive stone types such as marble, limestone and travertine, for both interior and exterior applications.
PRoduct Comparison
Stone Coatings Overview
Hover to scroll, click to hide/show
| Properties | 7620 Details |
704 / 705 Details |
7641 Details |
7626 Details |
8637 Details |
7622 Details |
7624 Details |
695 Details |
|---|---|---|---|---|---|---|---|---|
| PFAS-free | No | Yes | Yes | Yes | Yes | No | Yes | Yes |
| Use cases | Concrete, tiles (unglazed), roofing tiles, brick/masonry, limestone, sandstone, mineral plaster, natural stone, façade, slate | Concrete, plaster, natural stone (granite, slate, basalt, sandstone, limestone), roof tiles, clinker | Marble | Graffiti Protection for up to 50 times, for commercial locations, for aluminium siding, (fibre) glass, masonry, metal, street signs, stucco, utility boxes, vinyl siding, wood | For monuments, Statues, high value stone art works, paving-stone systems and terrace tiles | Wet room walls, concrete seating in public areas, stone foyer areas | Activated Hydrophobic + anti-mould coating (SiO2+TiO2) suitable for stones and porous painted surfaces | Concrete, plaster, natural stone (granite, slate, basalt, sandstone, |
| Application | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller | Brush, roller, convention or airless spray | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller | Spray, brush, roller |
| Application Temperature | <-10°C - 70°C | <5°C - 40°C | <15°C - 25°C | <-5°C - +60°C | <5°C - 30°C | <5°C - 30°C | 15°C - 25°C | <5°C - 50°C |
| m² per liter | 8 - 50 | 20 - 100 | 50 - 80 | 8 - 10 | 10 - 20 | 10 - 20 | 30 - 40 | 5 - 40 |
| Durability | 10 - 20 years | 5+ years | Up to 10 years | Up to 20 years | Up to 10 years | Up to three years | 2+ years | Up to 2 years |
| Curing Time | 3-6 hours at 20°C | 24 hours | 7 days at room temperature | Touch dry 3-4 hours, full cure 24 hours | 12 hours | 12 hours | 12 hours | 12 hours |
| … based | Solvent | Solvent | Solvent | Solvent | Water | Water | Water | Water |
| Available as concentrate | No | Dilutable up to 1:1 with Ethanol or 1-Methoxy-2-Propanol | No | No | No | No | No | Yes 1:9-1:14 (art. no. 697) |
| Breathable | Yes | No | No | Yes | Yes | Yes | Yes | Yes |
| Visible | Might be slightly darker | 704: Glossy 705: Matte |
Yes glossy |
Yes clearly (glossy) |
No on most surfaces |
No on most surfaces |
Matte, transparent | No on most surfaces |
| Topographical / penetrative | Penetrative, extreme abrasion-resistant | Topographical | Topographical | Topographical, very strong bonding | Topographical | Topographical | Solidifies the Surface | Topographical |
| Oil resistant | Yes | Yes | Yes | Yes | Yes | Yes | No | Yes |
| Frost resistant | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| PFOS- / PFOA-free | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Available in RAL colors | No | Yes from 1.000 liters |
No | Yes from 100 liters |
No | No | No | No |
| Dangerous goods | No | Yes | No | No | No | No | No | No |
